MSLVU02 Animal ultrasound machine - MSLVU02

1. Veterinary ultrasound scanner

2.Portable vet scanner

3. Handheld ultrasound scanner

4. Animal digital ultrasound

animal ultrasound machine

cattle ultrasound machine

Main specification

Probe element: 80 elements

Scanning mode: convex, linear

6.4' high resolution TFT LCD

Standard probe: 6.5MHz multi-frequency linear rectal probe

(frequency conversion scope:4.0 / 5.0 / 6.5 / 7.5 MHz)

 Optional Probe: 4.0MHz rectal linear probe

(frequency conversion scope:2.0 / 2.5 / 3.5 / 5.0 MHz)

Optional probe:3.5MHz convex multi-frequency probe

(Frequency conversion scope:2.0 / 2.5 / 3.5 / 5.0 MHz)

Optional probe:6.5MHz intra-vaginal frequency conversion probe

(frequency conversion scope:4.0 / 5.0 / 6.5 / 7.5 MHz)

Optional probe:7.5MHz frequency conversion probe

(frequency conversion scope:5.0 / 6.5 / 7.5 / 9.0 MHz)

Optional probe:5.0MHz micro-convex frequency conversion probe

(frequency conversion scope:3.5 / 4.5 / 5.0 / 5.5 MHz)

Scanning angle:convex probe 60°,intra-vaginal probe 135°

Body mark:1.General 2.Bovine, 3.Equine, 4. Canine, 5. Feline, 6.cardio

Probe socket: 1 socket, automatically identify the probe

Resolution:horizontal≤2mm,vertical≤1mm

Dead zone≤5mm(test report actually≤3mm)

Max scanning depth:≥17cm(test report actual ≥19cm)

Geometry position precision:Transversal≤10%,Longitudinal≤5%(test report actual≤5%, Longitudinal≤5%)

Scanning mode:B (B-mode Ultrasound Imaging (The Definition of B Mode Ultrasound )),2B,4B,B/M,M (M Mode Ultrasound Definition)

8 grades depth adjustment under full visual field (8kinds of magnification)

Gain: 0~127dB

Dynamic scope: 27~90dB, visible & adjustable

Four different angles / switchable width

Gray: 256

Imaging technique:full digital beam-composite, continuous dynamic focusing, dynamic aperture

Cine loop:256 frames

Permanent image storage: 100 frames

TGC control: near field, far field

Image processing:

pre-process (continuous dynamic focus, dynamic aperture, dynamic filter),

post-process(4 grades gamma correction),frame correlation, black/white reversal, left/right reversal, up/down reversal, edge enhancement, etc.

Depth hoist / local zooming

Frame frequency:30 frames/s
