Cheap portable color ultrasound scanner

1. Low price

2. High image quality

3. With two probes

4. Cardiac probe

5. Color ultrasound machine

                                                                   color doppler ultrasound scanner

 What is new?
Affordable Compact Excellent MSLCU01 is a compact color doppler ultasound system with various functions and applications. The high image quality and simple operation can help doctors perform and clinical exam, such as abdomen, smallparts, OB/GYN, cardiac, ect.

Full imaging mode: 2D, CFM, PDI, PW, HPRF, etc
1. Standard two transducer sockets with 15''LCD monitor
2. Full function control panel with back-lit and 8 level TGC
3.Selected transducers: Convex, Linear, Transvaginal, micro-convex etc.
4. Tissue Harmonic Imaging
5. iBeamTM: spatial compounding imaging reduces random noise and enhances border differentiation without compromising frame rate
6. iZoomTM: automatically expands the image to full screen
7. Full patient database solutions: DICOM3.0, AVI/JPG, USB2.0, HDD, PDF report, etc..

Expanded Functions:
1. iClear: image optimization, softer and more exquisite.(charging item)
2. B/C mode: CFM and B mode image displayed within one interface, easier for the doctor to browse and compare.
3. iTouch: one-click optimization.
4.THI: tissue Harmonic imaging for high frequency

Configuration:
Intel Core 2 Duo L9400
2 GB DDR-RAM
64GB SSD hard disk
Based on Windows XP

Friendly User Experience:
1. 2 Probe connectors
2. 4 USB ports, 1 Lan port, 1s-video port
3. AC adapter combined with wave filter, avoiding possible effect caused by unstable voltage.
4. Trackball and back light keyboard are easy to use.

Display mode

B&W mode: B, 2B, B/M, B/C

Color Doppler mode: 2D, CFM, PDI, PW, HPRF, etc

Triplex: Real-time simultaneous 2D, Doppler & CFM

Duplex: Real-time simultaneous 2D, Doppler

Gray scale: 256

Display: 15" LCD monitor

Transducer frequency: 2.5-10Mhz
Digital technology: Dynamic Receiving Focusing (DRF)
Dynamic Frequency Scanning (DFS)
Scanning depth: 300mm

Imaging Processing

Pre-processing:

                8-segment TGC

                Preset

                Gain (B&W, Color, Doppler)

                Audio

                PRF

                Dynamic Range

                Image enhancement

                Acoustic Power

Post-processing:

               gray map

               Black/white reverse

               Left/right reverse

               Up/down reverse

 Functions:

Cine-loop: 100 frame cine loop memory

Storage media: 64G massive image-storage capacity

Zoom: Pan zoom


USB ports: 4

THI: tissue harmonic imaging

Touch

Panoramic Imaging

Trapezoid Imaging

iClear Imaging

Measurement & Calculations

B mode: distance, circumference, area, volume, angle, fetal growth, curve

M mode: distance, time, velocity, heart rate

Software package: abdomen, gynecology, obstetrics, cardiology, small parts, urology


Others

Transducer connectors: 2 active transducer connector ports

Peripheral ports: video, S-video, VGA, 4 USB ports

Power supply: 100~240VAC±10%, 50Hz/60Hz

Transducers:

3.5Mhz Electronic convex array transducer

7.5Mhz Electronic linear array transducer

5.0Mhz Electronic micro-convex transducer

6.0Mhz Electronic transvaginal array transducer
